BLWP150 LED Driver - 150 Watt, 42V - Parking Lot Lighting, Maintenance

BLWP150 LED Driver – 150 Watt, 42V

$122.50

Title	Qty	Price
For BLWP LED Driver	11 +	$3.00 flat $119.50

SKU: BLWP150 Category: LED Retrofit

Features

Universal AC input/Full rang 90～305VAC
Built-in active PFC function
Protections: Short circuit/Over current/Over voltage
Cooling by free air convection
Built-in 3 in 1 dimming function (1-10VDC or 10V PWM signal or resistance)
Metal case, IP65 design for indoor or outdoor installations
Suitable for outdoor LED street lighting, outdoor LED and moving sign applications
Ultra-long life

150H-42
V: IP65Level，Io adjustable through built-in potentiometer
D: IP65Level，3 in 1 dimming function (1～10VDC,10V PWM signal and resistance)，Io adjustable through built-in potentiometer
SPECIFICATIONS

Parameter Name	Min.	Typ.	Max.	Unit
Input Voltage	100	110;230	277	Vac
Input Current	---	0.6	3	A
Power Factor	0.95	0.98	0.99	PF
THD	5	8	20	%
Frequency Rang	47	50\60	63	Hz
Output no-load Voltage	43	46	48	Vdc
Output Serving Voltage	36	42	43	Vdc
Output Current	-3%	1.6 -3.6	+3%	Adc
Overshoot	---	---	10	%
Ripple & Noise	---	---	300	mV
No Load Power	---	0.5	2	W
Efficiency	88	91	---	%（230VA）
Over Current Protection	---	---	110	%
Short Circuit Protection	Constant Current limiting, recovers automatically after fault condition is removed
Inrush Current(Typ.)	Col d Star t 65A( twidth=595us measured at 50% Ipeak)at 230VAC
MAX. No. of PSUs on 16A Circuit Breaker	4 units (circuit breaker of type B)/7 units (circuit breaker of type C) at 230VAC

BLWP150 LED Driver – 150 Watt, 42V
